Double the Width. Maximum Coverage.
Built on the same tactical DNA as the CX2, the CX4 Scene takes performance to the next level—literally. With twice the width and double the LED array, the CX4 delivers a massive 120° flood of pure white clarity, lighting up everything from your camp setup to your worksite with zero dead zones.
Engineered for roof racks, canopies, and high-mount locations, the CX4 Scene is your full-area flood solution when the job calls for maximum visibility in tight, high-use zones.
-
120° beam angle with smooth, even spread
-
Dual-array flood optics—no hotspots, no glare
-
Ideal for: Roof racks, campsite lighting, canopies, work zones, or tray lighting
-
Rugged blacked-out housing with IP69K water + dust rating
-
Compact dual-body form factor for wider output with low profile
-
DT plug & stainless mounting bracket for secure, simple install
Wider. Brighter. Built for Extreme Environments.
CX4 Scene — Illuminate everything. Miss nothing.
SPECIFICATIONS:
| WARRANTY | Life time |
| WATERPROOF RATING | IP69K |
| INPUT VOLTAGE | 10-32V DC |
| SAFETY | Reverse, over and under current protection. Thermal protection. |
| FINISH | DuPont Midnight Black - Non UV fading |
| LENS | GE Lexan |
| COLOUR TEMPERATURE | 6000K |
| CONNECTOR | DT04-2P Deutsche |
| HOUSING MATERIAL | 6063 Heavy Duty Die Cast Aluminum - Stainless Steel Bracket |
| LEDS | CREE 10W |
| Current amp draw | 2.2 @ 12V |
| Wattage | 26 watts @ 12V |
Dimensions:
What's included:
CX4 Scene LED work light (1)
Mounting Bracket with bolts (1)
DT Connector with break-out wire (1)
