STEDI Ford Ranger & Everest Lower Grill Light Bar Mounting Bracket MK2

  • Sale
  • Regular price R 1,899.00
  • Sold Out
Tax included. Shipping calculated at checkout.


Specifically designed to fit Ford Ranger (PX2/PX3) & Everest 2015 to 2022 all sub-models including XL, XLS, XLT, Wildtrak & FX4 / Trend, Ambiente & Titanium. Perfectly fits the STEDI™ ST3K 21.5" Light Bar in the lower grille opening. This is the graceful & robust lower grille mount you've been waiting for.





The Everest & Ranger are a few of the available offerings on the market with attractive front end right out of the box. Every detail of the lower grill mount has been carefully considered to ensure that depth & height remains cohesive with the overall front-end design. The end result is a perfectly located light bar that strikes the ideal balance between the aftermarket & original equipment vibe.





We’ve spent time designing and testing to ensure that the installation is fast & reliable. No drilling, no cutting, and no compromises. Manufactured from 3mm thick powder-coated stainless steel and folded in all the right places to ensure a vibration-free installation.


Designed to fit Ford Ranger MK2 (PX2) & Everest 2015 to 2018 (UA Chassis) all sub-models including XL, XLS, XLT, Wildtrak & FX4 | Trend, Ambient, Titanium. Will also fit Ford Ranger Raptor and the newer PX3 Ranger without a radar box in the lower grille.

Ranger Raptor and PX3 might require two holes to be drilled in the lower steel support as the pre-existing mounting holes are absent.

Manufactured with 3mm Stainless Steel with satin powder coat, and designed to be fastened to pre-existing holes which are already present on the inner steel support. This is a completely non-intrusive install meaning that no new holes need to be made, nor do sections of the front bumper need any cutting or modifying.

The end result is a very robust, stealth installation.


STEDI™ ST3K 21.5" LED Light Bar (Models with LHS Radar or no Radar)

STEDI™ ST3K 11.5" LED Light Bar (Models with Central Radar, one mounted on each side of the radar) *would require 2x Pairs of this bracket



  • Black Powder Coated Finish
  • 3 Series Stainless Steel
  • Designed to minimize disruption of air-flow
  • No need to remove the front bumper

Price is for the bracket only, light bars sold separately.



Material 3 series Stainless Steel
Finish Powder Coat



  • 1 x Set Ford Ranger / Everest Lower Grill Mounting Bracket
  • 2 x Stainless Steel Bolts
  • 2 x Flat Stainless Steel Washer
  • 2 x Nylock Nut
